CUSTOM ANGLED LED STRIP FOR UNDER-CABINET AND COOKTOP
Illuminate your kitchen with style and precision thanks to our custom LED strip for under-cabinet lighting and cooktop. Our 30° angled LED bar is extremely versatile and perfect for illuminating a variety of spaces and environments such as: desks, work surfaces, walk-in closets, bookshelves, and much more.
The main feature of this custom LED strip model is the presence of an invisible fastening hook system. In fact, the hooks (included in the package) are attached to the back of the profile. This structure allows hiding the fastening hooks and exposing only the elegant structure of the LED lamp. Additionally, the 30° angle allows the light to be projected mainly onto the underlying surface.
Configure your LED lamp with a flat profile in detail: it is designed to adapt to your needs and, above all, is ready to use with easy and quick installation!
Our custom LED strips are crafted in our workshop with extreme precision and attention to detail.
Our custom LED strips are made with top-quality professional components. The structure is made with highly heat-dissipating aluminum 6063 profiles. The high heat dissipation capacity ensures a long lifespan for the lamp and the integrity of the installed LED strip. The LED lamp will be provided with a professional power supply with a flame-retardant shell, protections against short circuits, overheating, and overvoltage. It also has a quick connector and a bypass plug that allows you to install your strip in less than a minute.
We offer a KING LED 3-year warranty.
Our packaging process is designed to ensure maximum protection against scratches and bends during shipping. Your LED strip will arrive at its destination in perfect condition.
DISCOVER HOW TO CUSTOMIZE YOUR CUSTOM LED LAMP:
Length from 30 to 300cm: Choose the perfect length for your space, from a minimum of 30 cm to a maximum of 300 cm. Uncompromising adaptability to ensure bright and uniform light. If you desire specific lengths, contact us via email at info@kingled.it. NB: We ship up to 2 meters in length. For lengths exceeding 210 cm, shipments are not available; only pickup or shipment organized with your courier.
Choose the Cover Type: For a final touch of elegance, select the cover you prefer among transparent, opaque, or black. Besides providing additional protection, the cover helps modulate the lighting effect according to your preferences.
Choose from 4 Available Colors: Customize the aesthetics of your LED strip by selecting the profile color among anodized, titanium, black, and white. Choose the color that best matches your style and the design of your surroundings.
Choose from 4 Available Light Temperatures: Choose the light temperature you prefer among very warm light (2700K), warm (3000K), cool (6500K), or natural (4000K). The choice of temperature must be made before purchase and cannot be changed later. Create the perfect environment for every moment, from cooking to relaxing.
CHOOSE THE CONTROL SYSTEM FOR YOUR CUSTOM LED STRIP:
Customize your LED lamp 100% and choose how to manage your lighting. Our workshop will be happy to install the control system you prefer based on your needs. Please note that installing a sensor will not allow management from a wall button/switch. If you want to connect your custom LED strip to a switch, you will need to purchase the version without a dimmer. Here are the available control systems:
- ▪ Touch Dimmer: You can turn on, turn off, and adjust the brightness by touching the touch sensor on the strip. The touch dimmer is extremely sensitive and equipped with a blue light indicator to easily locate its position on the strip, as well as having a memory that maintains the last brightness setting upon each new turn on.
- ▪ Proximity Dimmer hands: Very convenient when your hands are dirty or wet, as you can turn on, turn off, and adjust the brightness by passing your hand in front of the sensor without touching the custom LED lamp (detects the signal up to 5 cm away). The dimmer has a memory, so the last brightness setting will be retained.
- ▪ PIR Motion Sensor: Ideal for automatically illuminating passage areas such as utility rooms, hallways, and staircases. The LED strip with motion sensor will turn on and stay on as long as the sensor detects movement (detects movements with an angle of 120° and a distance of up to 5 meters). If no movements are detected, it will automatically turn off after 60 seconds. This solution does not allow brightness dimming.
TECHNICAL SPECIFICATIONS:
Profile Type: Angled with a 30° projection
Profile Size: 20x16 mm
Material: Aluminum 6063
Available Colors: Silver (anodized), Black, and White
Length: Customizable from 30cm to 300cm
Power: 12.8 W/mt (a two-meter lamp will absorb 25.6W)
Brightness: 1400 Lm/mt (a two-meter lamp will develop 2800 lumens)
Light Temperature: Choose from 2700K, 3000K, 4000K, 6500K.
Control System: Choose between touch dimmer, proximity dimmer, and motion sensor
Dimmable: Yes (except with PIR motion sensor)
Power Supply: DC 24V Included
Fastening Hooks: Included (2 hooks provided for every meter of length)
CABLE LENGTHS:
Strip output cable with FEMALE connector (connect to the power supply): 180cm cable, customizable upon request.
Power supply output cable with MALE connector (connect to the strip): 150 cm cable
Power supply input cable with Bypass Plug: 120 cm cable
