Led Strip CCT CRI90 24V 80W 6500lm Dual White 2700K - 6500K IP65 600 SMD coil 2835

Dual white dimmable led strip with waterproof dynamic white for outdoor environments with 80W 24V power

DESCRIPTION

CCT Led Strip with Variable Kelvin Degrees from 2700K to 6000K
Supply voltage DC 24V (Power supply not included)
Led Strip Dimmable and Cuttable to every 12 Led (100mm)
Nominal Power 80W per Coil / Power Consumption 16 W / mt
Nominal Lumen 6500lm per Coil / Effective Lumen 1300 lm / mt
IP65 waterproof led strip for outdoor environments

Led strip 2835 of 5 meters, mounted on 3M double-sided tape.
120Led / mt (600 total LEDs, 300 cold light LEDs and 300 warm light LEDs) this Led strip can be cut to every 12 LEDs (Every 100mm).

By means of a Mi-Light controller it allows you to mix the two shades of Light, creating a Variable Kelvin gradation from 2700K to 6000K.
Thanks to this led strip you can create all the shades of white light you prefer at any time.

The connection of several Led strips must be carried out in parallel.
For installation it is necessary to use aluminum profiles for dissipation.

Warning: If you cut the strip this coil loses its iP65 waterproof rating

DATA SHEET:

Led number: 600 (120 / mt)
Rated power: 80W (16W / mt)
Power supply voltage: DC24V
Dimmable: Yes
Led type: SMD2835
Nominal Luminous Flux: 6500Lm (1300 Lm / mt)
Efficiency: 81 Lm / W
Color Temperature: Variable from 2700K to 6500K
Light angle: 120 °
Color rendering index: 90+
Strip length: 5000mm
Width: 10.5mm
Cutting Segment: 12 LEDs / 100mm
Height: 2mm
PCB color: White
Protection: IP65 heat shrink
Certificates: TUV, RoHS
Warranty: 3 Years

CORRECT INSTALLATION

To ensure maximum performance in terms of light output and duration, installation on a special aluminum profile is mandatory, designed for correct heat dissipation.

The aluminum profiles not only dissipate heat, but also protect the LED strips from dust, insects and partially moisture.

PROPER NUTRITION

The LED strips must be powered with a constant voltage power supply, usually with the DC symbol. A DC 24V power supply is required for the 24V led strips.

To calculate the required wattage of the power supply to buy for your led strip, just do a simple mathematical multiplication:

"N ° meters of led strip x Watt per meter absorbed by the strip model = Essential power of the power supply"

Warning: Always buy a slightly more powerful power supply for the result obtained, otherwise your power supply would always work at full load and you would risk burning it.

"Ex: You have 3 meters of 20W LED strip per meter and you want to buy a power supply, the operation to be done will be this: 20 W x 3mt = 60W total absorption for 3 meters of LED strip. You will therefore need a power supply unit of at least 100W "

Remember that the 24V led strips, powered at one end, can reach a maximum length of 5m. To reach higher lengths it is mandatory to feed the strip to both ends or in 5m sections.

Always use a power supply with a power greater than the power of the led strip.

DIMMERATION

To adjust the light intensity of a LED strip it is necessary to use a suitable controller.

You can dim the LED strips with a WiFi controller, from the Button, use Alexa's voice control, remotely manage via Smartphone and also set a timer.
