Control and dim your lights to create the right atmosphere. Easy installation, Suitable to use with all Mi-Light Single Colour Mi-Light products.
FUNCTIONS: Dim your light from 0% to 100%. Brightness Adjustable: Adjust the brightness according to your requirement. 9 color changing modes: choose the color and atmosphere you want.Take care of your family! Long Press OFF button to Night Light Mode, convenient for the night and getting up in the dark. Switch-off delay function (60 seconds). Memory Function, WHEN SHUT OFF, the present settings will be saved and the pre-set operation will resume when the power is on again. Sensitive Touching (High Precision Capacitive Touch Screen IC and very stable.)
DOMOTIC SYSTEM: A great start for those who want to create a domotic system with lighting control. You will be able to manage the entire line of Single Colour Mi-Light Products, easily and fast. A wide range of products for indoor, outdoor, private and commercial use. 4-Zones Control, can control endless Mi-Light products simultaneously. 2.4GHz Wireless Transmission, Strong Anti-Interference, Long-distance transmission, 30 meters . Input Voltage: 3V (2*AAA Battery, NOT included).
START YOUR SMART LIFE: This intelligent panel allows you to control different zones. It is possible to create up to four separate zones, such as the dining room, living room, bedroom and kitchen. Easy installation, no wiring, moving easily, sensitive touching, scratch resistance. All lights effects can be realized according to your preference or mood, just enjoy the dynamic life fulfilled with our lighting system and start your smart life!
WARRANTY: KingLed offers product warranty service for all Mi-Light products and provides fast and comprehensive customer service before, during and after the purchase
KingLed is absolutely an authorized Mi-Light reseller and only sells original products in original packaging. Smart Panel B1, 4-Zones Mi-Light Remote Control, Wi-Fi(2.4Ghz) Controller for Single Colour LED Lights. Easy installation, no wiring, moving easily, sensitive touching, scratch resistance, start your smart life!This intelligent panel allows you to control different zones. It is possible to create up to four separate zones. All lights effects can be realized according to your preference, enjoy life fulfilled with our lighting system.
With a compatible Mi-Light remote controller, you can dim and control single-colour LED strips remotely, through the following functions:
Switch ON / Switch OFF
0%-100% smooth dimming capacity
4-ZONES CONTROL, controll each zone separately or simultaneously.
30m control distance
Switch-off delay function (60 seconds).
This product can be powered with batteries (2x AAA Mini Stylus), and can connect to AC220v directly, with a Mi-Light driver.
DATASHEET:
Panel Remote Controller
Model: B1
Input Voltage: 3V/ Plug-In 3,2V(2*AAA Battery)
Transmission power: 6dBm
Standby Power: 20uA
Transmission Frecuency: 2400-2483.5 MHz
Modulation Method: GFSK
Control Distance: 30m
Working Temperature: -20~60℃
Dimensions: 86x86mmCertifications: CE / RoHS
IMPORTANT: You need to synchronise before the usage to ensure that the product works properly: Please ensure the remote control is compatible with your product. Switch OFF the LED light Switch ON the LED light When the LED lights up, press the "ON" button repeatedly. Once the sync has finished successfully, the LED Light will light up three times.
